Can really recommend this blog post series: Bare-metal Kubernetes, Part I: Talos on Hetzner

In my blog post I cover:

• updated Talos Script Install
• how to use Hetzner Cloud Load Balancer with vSwitch

The installer script got a bugfix because the old download links are not more working. Talos provies now raw.zst download links instead of tar.gz.

TALOS_VERSION="1.11.2"
TARGET_DISK="/dev/nvme0n1"

wget -O /tmp/talos.raw.zst https://github.com/siderolabs/talos/releases/download/v$TALOS_VERSION/metal-amd64.raw.zst

zstd -d /tmp/talos.raw.zst -o /tmp/disk.raw
# Write the raw disk image directly to the hard drive.
dd if=/tmp/disk.raw of=$TARGET_DISK && sync
reboot

vSwitch and Hetzner Cloud Load Balancer

network Configuration

  machine:
    kubelet:
      network:
        hostname: 'talos-example-1'

    interfaces:
      - deviceSelector:
          busPath: '0*'
        dhcp: true
        vlans:
          - addresses:
              - 10.200.1.11/24
            routes:
              - network: '10.200.0.0/16'
                gateway: '10.200.1.1'
            mtu: 1400 # set by Hetzner
            vlanId: 4142 # set by Hetzner vSwitch

OpenTofu: Hetzner Cloud Load Balancer

And the OpenTofu Code for creation of the Cloud Load Balancer:

resource "hcloud_load_balancer" "example" {
  name               = "kubernetes"
  load_balancer_type = "lb11"
  location           = "nbg1"
  delete_protection  = true
}

resource "hcloud_load_balancer_network" "example" {
  load_balancer_id = hcloud_load_balancer.example.id
  network_id       = data.hcloud_network.main.id
}

resource "hcloud_load_balancer_target" "talos_example_1" {
  type             = "ip"
  load_balancer_id = hcloud_load_balancer.example.id
  ip               = "10.200.1.11"
}

resource "hcloud_load_balancer_target" "talos_example_2" {
  type             = "ip"
  load_balancer_id = hcloud_load_balancer.example.id
  ip               = "10.200.1.12"
}

resource "hcloud_load_balancer_target" "talos_example_3" {
  type             = "ip"
  load_balancer_id = hcloud_load_balancer.example.id
  ip               = "10.200.1.13"
}

resource "hcloud_load_balancer_service" "apiserver" {
  load_balancer_id = hcloud_load_balancer.example.id
  protocol         = "tcp"

  listen_port      = "6443"
  destination_port = "6443"
}

resource "hcloud_load_balancer_service" "http" {
  load_balancer_id = hcloud_load_balancer.example.id
  protocol         = "tcp"

  listen_port      = "80"
  destination_port = "30080"
}

resource "hcloud_load_balancer_service" "https" {
  load_balancer_id = hcloud_load_balancer.example.id
  protocol         = "tcp"

  listen_port      = "443"
  destination_port = "30443"
}
